LUMINAIRE

LIT
BAFFLE


Discover Rensa Lit Baffles—
the world’s only real wood, acoustic luminaires.

A versatile, modern profile, the Rensa Lit Baffles integrates exceptional lighting and top-performing sound absorption into one attractive solution.

Designed to complement SoundPly Acoustic Baffles, Planks and Panels for a total room solution with matching real wood finishes.

SPECIFICATIONS



ACOUSTICS

With SoundPly surface treatment:
RF Core – 0.90 NRC
LR Core – 0.80 NRC
ASTM C423, F6 Direct Mount



MATERIAL
Core consists of RF fiberglass or LR mineral wool. Recycled content:
30% Post-consumer (RF)
21% Pre-consumer (LR)
Surface consists of thermally fused layers of
fiberglass reinforced polymer and/or MDF



FINISH
Real wood veneer, species as selected
Painted MDF finish, color as selected



OPTICS
Direct: Diffuse
Indirect: Dust Cover or Batwing
90 CRI



ELECTRICAL
Voltage: (120/277V) Universal
1% Dimming, 0-10V



LUMINAIRE
Reflectors fabricated of 22 Ga. steel
Matte White powder coat finish
Extruded acrylic lens 0.05 in. thick
with frosted finish
Up to 8’ continuous



MOUNTING
Pendant, suspended by aircraft cable



FIRE RATING
Class A, ASTM E84


ENVIRONMENTAL
For use up to 25 °C ambient
25%-55% relative humidity
Dry locations only



LEED
1. MR Recycled Content
2. MR Material Ingredients
3. EA Optimized Energy Performance
4. EQ Enhanced Acoustical Performance
5. EQ Interior Lighting
6. EQ Daylight
7. EQ Low Emitting Materials (RF core)



MAINTENANCE
Baffle Housing – see SoundPly
Maintenance Instructions


Luminaire – see Rensa Lit Baffle
Maintenance Instructions



WARRANTY
1-Year Housing
5-Year Luminaire



UL LISTING

Luminaires, UL1598

Surface Treatment
• SoundPly (Micro-perforated)
• AeroPly    (Not perforated)

Acoustic Core
• RF Series (0.90 NRC)
• LR Series (0.80 NRC)

Thickness
• 2″

Height
• 5.75″
• 7.75″
• 11.75″
• 23.75″
• Custom (between 6″ and 24″)

Length
• 48″
• 72″
• 96″

Direct Light – Engine (LM/FT)
• NONE
• 300
• 400
• 500
• 650
• 800

Direct Light – Optics
• Regress Lens (Standard)

Indirect Light – Engine (LM/FT)
• NONE
• 375
• 500
• 625
• 800
• 950

Indirect Light – Optics
• Dust Cover (Standard)
• Batwing

Color Temperature
• 3000K, 80 and 90 CRI
• 3500K, 80 and 90 CRI
• 4000K, 80 CRI only

Circuiting
• Single Circuit
• Double Circuit

Cord Length
• 24″
• 48″
• 96″

Cord Type
• Standard
• Plug

Actual sizing shown, though dimensions may be referenced to as nominal heights.

WOOD SPECIES

Anegre
Quarter Slice

Burmese Teak
Plain Slice

Douglas Fir
Quarter Slice

European Beech
Quarter Slice

Makore
Plain Slice

Maple
Plain Slice

Smoked Eucalyptus
Quarter Slice

Walnut
Plain Slice

Wenge
Quarter Slice

White Ash
Rift Slice

White Oak
Rift Slice

715+ Additional Wood Species/Slice/Grade Combinations
In Stock

SPECIALTY FINISHES

Arctic Oak

Cider Rift Oak

Iron Rift Oak

Saddle Oak

Sawcut Oak
Natural

Sawcut Oak
Washed

Surly Oak

Vintage Oak

Arctic White

Blackout Ash

Custom Paint Colors Available

Custom Stains & Sheens Available
